KIA CARENS III RIGHT-SIDE

Name: KIA CARENS III RIGHT-SIDE
Brand: Depa
SKU: 3580800
Price: 271.01 EUR
Availability: OutOfStock

Ref : 3580800

Matching vehicles :

CARENS III

Family :TR

Height : 15 mm

Compressed length : 955 mm

ABS on the vehicle : Yes

Thread pitch type : 22X150

Nut type : Crown

COTE BOITE

Diameter (big) : 72 mm

Diameter (little) : 25.5 mm

Seal seat diameter : 41 mm

Outer spline diameter : 28 mm

Housing diameter : 76 mm

Beads thickness : 9 mm

Length : 102 mm

Length of the gearbox output without seal seat : 61 mm

Number of external splines : 27

Type of material : Neoprene

COTE ROUE

Diamètre (grand) : 83 mm

Diamètre (petit) : 22 mm

Diamètre des cannelures extérieures : 28 mm

Diamètre du bol : 87 mm

Shoulder diameter : 62 mm

Longueur : 79 mm

Nombre de cannelures extérieures : 27

Number of splines on inner race : 25

Number of grooves : 1

Type de matière : NÉOPRÈNE

Type and position (snap ring/circlip) : Centered snap ring

COURONNE ABS COTE ROUE

Outer diameter : 87 mm

Inner diameter : 72 mm

Width : 15 mm

Number of teeth : 48

Fixation	COTE ROUE	EC015
Fixation		EC042
Sealing kit	COTE ROUE	5005
	COTE BOITE	6055
	COTE BOITE	6194
CV joint	COTE ROUE	JK08
ABS ring		COU110

Equivalence to manufacturer references

KIA : 495001D751
